Mass-Dependent Integral Curves in Unsteady Vector Fields
Computer Graphics Forum (Eurographics Conference on Visualization), 2013
Abstract
Recent research in flow visualization is focusing on the analysis of time-dependent, but mass-less particles. However, in many application scenarios, the mass of particles - and their resulting inertia - is essential in understanding fluid mechanics. This includes critical processes, such as dust particles interacting with aircraft (e.g., brown- or white-out effects) and particle separation based on density variation. In this paper, we contribute a generalized description of mass-dependent particle trajectories and apply existing unsteady flow visualization methods to the mass-dependent case. This comprises the extension of common concepts, i.e., path lines, streak lines, and time lines. Furthermore, we introduce a new class of integral curves, called mass lines that effectively visualizes mass separation and captures mass-related features in unsteady flow fields that are inaccessible using traditional methods. We demonstrate the applicability of our method, using a number of real-world and artificial data sets, in which mass is a crucial parameter. In particular, we focus on the analysis of brown-out conditions, introduced by a helicopter in forward flight close to the ground.
Download
preprint
video
doiVideo
BibTeX
@article{Guenther13EuroVis,
author = {G{\"u}nther, Tobias and Kuhn, Alexander and Kutz, Benjamin M. and Theisel, Holger},
title = {Mass-Dependent Integral Curves in Unsteady Vector Fields},
journal = {Computer Graphics Forum (Eurographics Conference on Visualization)},
volume = {32},
number = {3},
pages = {211--220},
year = {2013},
publisher = {Eurographics},
address = {Leipzig, Germany},
doi = {10.1111/cgf.12108},
}
